Overview
The Heizka Connector Kit joins two sections of channel, or a section of channel to a fitting, to build a continuous fibre pathway. Bolts tighten and release by finger on the 60 mm Type A connector, so a straight joint can be made and re-made without tools.
Connector kits are the basic building block of the system: every elbow, tee and cross is fixed to the run with the connector kit for its series, and the number required is listed against each fitting.
Key Features
- Joins channel to channel, or channel to fittings, in one component.
- 60 mm Type A connector needs no screws for normal installation – absolutely toolless.
- Available across the 60, 120, 240, 360 and 600 mm series.
- Allows a run to be extended or re-routed later without removing installed fibre.
- Self-extinguishing plastics – flame-retardant material to UL94-V0.
Technical Specifications
| Series | Item No. | Name | W (mm) | H (mm) | Overall (mm) | Colour | Material |
|---|---|---|---|---|---|---|---|
| 60 | 311A0 | 60mm Connector A type | 60 | 60 | 90 × 50 × 54 | Yellow | PVC/ABS |
| 120 | LL232 | 120mm Type B connector kit | 120 | 100 | 169 × 84 × 122 | Yellow | PVC/ABS |
| 240 | LL262 | 240mm Type B connector kit | 240 | 100 | 289 × 84 × 122 | Yellow | PVC/ABS |
| 360 | LL281 | 360mm Type A connector kit | 360 | 100 | 420 × 100 × 129 | Yellow | PVC/ABS |
| 600 | 312A0 | 600mm Type A connector kit | 600 | 100 | 642 × 80 × 121 | Yellow | PVC/ABS |
Installation notes
- 60 series: no screws are needed for normal installation.
- 120 and 240 series: supplied with 8 pieces of round head screw (LT5B4).
- 360 series: installation needs plastic round head screw and square nut, 10 pieces each.
- 600 series: installation needs plastic round head screw and square nut, 14 pieces each.
- Flame retardant: UL94-V0.
Dimensions are quoted from the Heizka Fibre Management System catalogue. Specifications are subject to change without notice – please confirm critical dimensions with Heizka before ordering.
Standards & Compliance
- Flame retardancy: UL94-V0 self-extinguishing plastics.
- Material: PVC / ABS mouldings; steel support hardware is electroplated zinc with a powder-coated finish.
- All plastic-based components are specified to be RoHS compliant.
- Colour: high-visibility yellow, identifying the fibre pathway.
- Environment: indoor use in data centres, telecommunication exchanges and equipment rooms.
Typical Applications
- Data centres and server rooms – fibre patch cord routing between racks and rows.
- Telecommunication exchanges and central offices.
- Optical distribution frames (ODF) and fibre cross-connect areas.
- Any installation where fibre must be segregated from copper services and protected end to end.
Download
Catalogue extract for this product, taken from the Heizka Fibre Management System catalogue:
