Overview
The Heizka Cross Arm range is the steel hardware that carries the fibre raceway. Single-hole and dual-hole bars support the run from one or two threaded rods; wall brackets carry it directly off a wall.
All cross-arm hardware is electroplated zinc with a powder-coated finish, and lengths are matched to the 120, 240 and 360 mm raceway series.
Key Features
- Single hole bar for single threaded rod supports; dual hole bar for double threaded rod supports.
- Wall bracket suits all fibre raceway sizes within 240 mm; length can be extended to suit site conditions.
- Lengths matched to the 120, 240 and 360 mm series.
- Electroplated zinc with powder-coated finish for indoor corrosion resistance.
- Works with the Heizka plastic T-shape bolt and twist nut fixings for fast attachment to the raceway.
Technical Specifications
Single Hole Bar
| Item No. | L (mm) | Overall (mm) | Application range | Surface treatment |
|---|---|---|---|---|
| LI2D1 | 120 | 230 × 47 × 12 | 120 straight section | Electroplated zinc, powder coated |
| LI2D2 | 240 | 350 × 47 × 12 | 240 straight section | Electroplated zinc, powder coated |
| LI2D3 | 360 | 450 × 50 × 23 | 360 system straight section | Electroplated zinc, powder coated |
Suits various single threaded rod mounting supports.
Dual Hole Bar
| Item No. | L (mm) | Overall (mm) | Application range | Surface treatment |
|---|---|---|---|---|
| LI2S1 | 300 | 300 × 50 × 15 | 120 straight section | Electroplated zinc, powder coated |
| LI2S2 | 400 | 400 × 50 × 15 | 240 straight section | Electroplated zinc, powder coated |
| LI2S3 | 500 | 500 × 50 × 15 | 360 system straight section | Electroplated zinc, powder coated |
Suits various double threaded rod mounting supports.
Wall Bracket
| Item No. | L (mm) | Overall (mm) | Application range | Surface treatment |
|---|---|---|---|---|
| LI2Q1 | 230 | 230 × 50 × 100 | 120 straight section | Electroplated zinc, powder coated |
| LI2Q2 | 350 | 350 × 50 × 100 | 240 straight section | Electroplated zinc, powder coated |
Suits all fibre raceway sizes within 240 mm; length can be prolonged according to the site situation.
Dimensions are quoted from the Heizka Fibre Management System catalogue. Specifications are subject to change without notice – please confirm critical dimensions with Heizka before ordering.
Standards & Compliance
- Flame retardancy: UL94-V0 self-extinguishing plastics.
- Material: PVC / ABS mouldings; steel support hardware is electroplated zinc with a powder-coated finish.
- All plastic-based components are specified to be RoHS compliant.
- Colour: high-visibility yellow, identifying the fibre pathway.
- Environment: indoor use in data centres, telecommunication exchanges and equipment rooms.
Choosing a Suspension Method
Most fibre routes in a data hall or equipment room are hung from the slab above the cabinet rows. The cross-arm range gives three ways to do this: a bar on one threaded rod, a bar on two threaded rods, or a bracket fixed to a wall. A single rod is quick to set out and suits narrow channels on short spans. Two rods hold the bar level and resist twisting, which matters on the wider 240 and 360 series or where fittings such as tees load one side of the route. Wall brackets carry the run along a perimeter wall where no slab fixing is possible.
Bar Length against Raceway Width
Each bar is matched to a raceway series. The table compares bar length with the published overall width of that series (channel including flange and cover).
| Part | Size (mm) | Raceway series | Overall width | Bar length beyond raceway (calculated) |
|---|---|---|---|---|
| LI2D1 | 230 × 47 × 12 | 120 | 158 mm | 72 mm |
| LI2D2 | 350 × 47 × 12 | 240 | 278 mm | 72 mm |
| LI2D3 | 450 × 50 × 23 | 360 | 396 mm | 54 mm |
| LI2S1 | 300 × 50 × 15 | 120 | 158 mm | 142 mm |
| LI2S2 | 400 × 50 × 15 | 240 | 278 mm | 122 mm |
| LI2S3 | 500 × 50 × 15 | 360 | 396 mm | 104 mm |
The extra length is where the rods, nuts and clamps sit. A longer bar gives more room between the rods and the channel, which helps when the raceway shares the ceiling zone with other services. Confirm the bar type for each code against the kit list in the technical specifications above.
Setting Out the Route
- Fix rod positions so the raceway runs straight above the cabinet rows and drops (spillouts or exits) land over each cabinet’s cable entry.
- Add a support close to every fitting — elbows, tees and crosses — as well as along straight runs, at the spacing set by the designer.
- Keep rods clear of the snap-on cover so the cover can be opened along the whole route for moves and changes.
- All cross-arm hardware is electroplated zinc with a powder-coated finish for indoor use.
Related Products
- Mounting hardware kits — complete kits for ceiling, ladder rack and access-floor mounting.
- Cabinet top support — for routes that sit on the cabinet row.
- 360 series raceway and 240 series raceway.
Back to the Fiber Raceway System.
Typical Applications
- Data centres and server rooms – fibre patch cord routing between racks and rows.
- Telecommunication exchanges and central offices.
- Optical distribution frames (ODF) and fibre cross-connect areas.
- Any installation where fibre must be segregated from copper services and protected end to end.
Download
Catalogue extract for this product, taken from the Heizka Fibre Management System catalogue:
